50 TPD Rice Processing Plant

  • Raw material:Carbon Steel , Stainless Steel
  • Capacity:1T/D,5T/D,10T/D,20T/D ETC.
  • Usage:Rice Processing
  • Port:QINGDAO ,SHANGHAI
  • Delivery time:30 DAYS
  • After-sales service:FREE INSTRUCTION

We're here to help: Easy ways to get the answers you need.


1.Chart flow of Rice Processing Equipment:

Cleaning - soaking - steaming - drying - husking - milling - polishing and grading - corlor sorting - packing. We can supply a complete plant and offering installing service.







2.Process flow of Rice Processing Equipment:

1) Cleaning

In this stage we remove the dust from the paddy,if the paddy has dust when it is soaking it will pollute the water and influence the nutrition of rice.

2) Husking.

After soaking and steaming it will be very easy to husk the paddy and save energy.

3) Milling.

The pearling of pre-boiled rice cost much more time than normal paddy.

The reason is that after soaking the rice is easy to become smectic. In order to avoid this problem we use blowing rice miller, and increase the rotating speed of rice miller,the rice bran transmission adopt neaumatic type to reduce the friction.

4) polishing and grading

Grading machine is used to separate different quality rice and separate broken rice from the good ones.

Good rice come through the polishing machine, it will make the milling rice become more beautiful color and more smooth, thus to increase the quality of rice.

5) Color sorting

The rice we get from above step still has some bad rice, broken rice or some other grains or stone. So here we use color sorting machine to select the bad rice and other grains. Color sorting machine is an important machine to ensure we can get high quality rice.

6) Packing.

The finish rice now is ready dear all! Let's use our automatic weighing and packing machine to make them into 5kg 10kg or 50kg bags. This machine is electric type, you can set it like a small computer, then it will start working according to your request.



3.Process Flow of Rice Processing Equipment:



4.Working Video of Rice Processing Equipment:
